BAGGAGE RACK (1200) | 12-1200-27
BAGGAGE RACK (1200) | 12-1200-27 — OPTIONAL EQUIPMENT (12), SHERP N (PRO XT). Includes 21 parts with OEM numbers and cross-references. Click hotspots on the manual to find the right SHERP part.· 21 parts
| 1 | Baggage rack | 11200-04600-N0A | 1 | |||
| 2 | Frame | 11200-05000-N0A | 1 | |||
| 3 | Frame | 11200-04900-N0A | 1 | |||
| 4 | Bracket | 11200-04700-N0A | 2 | |||
| 5 | Crossbar | 11200-05100-N0A | 1 | |||
| 6 | Bracket | 11200-05200-N0A | 2 | |||
| 7 | Insert plate | 11200-04800-N0A | 2 | |||
| 8 | Bracket | 11200-05300-N0A | 6 | |||
| 9 | Bracket | 11200-05600-N0A | 6 | |||
| 10 | Clamp | 11506-00200-XXA | 14 | |||
| 11 | Screw | 11502-08100-N0A | 28 | |||
| 12 | Nut | 11503-02900-XXA | 28 | |||
| 13 | Nut | 11503-00800-XXA | 09.0417 | 16 | Price on request | |
| 14 | Bolt | 11501-05700-XXA | 09.0100 | 16 | Price on request | |
| 15 | Washer | 11504-06900-XXA | 12.0042 | 16 | Price on request | |
| 16 | Bolt | 11501-08000-XXA | 16 | |||
| 17 | Washer | 11504-05800-XXA | 09.0292 | 28 | Price on request | |
| 18 | Plug | 10200-90200-N0A | 28 | |||
| 19 | Nut | 11503-10700-XXA | 16 | |||
| 20 | Bolt | 11501-00300-XXA | 16 | |||
| 21 | Bolt | 11501-07900-XXA | 12 |
