SEAT, REAR FOLDABLE (1200) | 12-1200-17

SEAT, REAR FOLDABLE (1200) | 12-1200-17 — OPTIONAL EQUIPMENT (12), SHERP N (PRO XT). Includes 8 parts with OEM numbers and cross-references. Click hotspots on the manual to find the right SHERP part.· 8 parts

#TitlePart numberCross part numberQtyPrice
1Seat10602-01000-N0A1$669 CAD
2Seat10602-00600-N0A10602-01000-N0A1$669 CAD
3Screw11502-05100-XXA04.02814Price on request
4Screw11502-11400-N0A2
5Handrail10400-01200-XXA1
6Nut11503-10400-XXA2
7Washer11504-11500-N0A4
8Nut11503-00800-XXA09.04174Price on request
Manual sheet 11Viewing
Manual sheet 22
