LIFE JACKETS, 6 pc. INSTALLATION (1200) | 13-1200-24

LIFE JACKETS, 6 pc. INSTALLATION (1200) | 13-1200-24 — RESCUE EQUIPMENT (13), SHERP N (PRO XT). Includes 10 parts with OEM numbers and cross-references. Click hotspots on the manual to find the right SHERP part.· 10 parts

#TitlePart numberCross part numberQtyPrice
1Full set11200-09500-N0A1
2Screw11502-10600-N0A6
3Nut11503-00800-XXA09.041720Price on request
4Washer11504-05100-XXA20
5Bracket11200-02700-XXA2
6Screw11502-06400-XXA14
7Rivet11507-01300-XXA02.01216Price on request
8Plate 11200-02800-XXA1
9Box11200-02500-XXA1
10Life Jacket11200-02600-XXA6
Manual sheet 11Viewing
Manual sheet 22
