FRONT WINDOW (0400) | 04-0400-03
FRONT WINDOW (0400) | 04-0400-03 — WINDOWS AND DOORS, BLINDS (04), SHERP N (PRO XT). Includes 39 parts with OEM numbers and cross-references. Click hotspots on the manual to find the right SHERP part.· 39 parts
| 1 | Front Window Assembly | 10403-03800-N0А | 090-1706 | 1 | $1232.5 CAD | |
| 2 | Nut | 11503-02500-XXА | 04.0247 | 4 | $1.5 CAD | |
| 3 | Nut | 11503-00900-XXА | 04.0296 | 4 | Price on request | |
| 4 | Insert plate | 10403-03000-N0А | 2 | |||
| 5 | Wiper blade (long) | 10400-02400-XXA | 04.0133, 090-0303, 04.0133-S, 04.0121-A 090-0303 | 1 | $13 CAD | |
| 5 | Wiper blade (short) | 10400-02400-XXA-S | 04.0133, 090-0303, 04.0133-S, 04.0121-A 090-0303 | 1 | Price on request | |
| 5 | Windshield wiper blade | 10400-02100-XXА-A | 04.0133, 090-0303, 04.0133-S, 04.0121-A 090-0303 | 1 | $14 CAD | |
| 6 | Veil | 10400-01600-XXА | 04.0044 | 2 | $29.5 CAD | |
| 7 | Washer | 11504-04300-XXА | 04.0043 | 8 | Price on request | |
| 8 | Washer | 11504-02500-XXА | 03.0450 | 8 | Price on request | |
| 9 | Screw | 11502-03200-XXА | 4 | |||
| 10 | stud | 10403-01700-N0А | 4 | |||
| 11 | Actuator | 10403-03600-N0А | 090-0357 | 1 | $391.5 CAD | |
| 12 | Strut | 10403-00500-N0A | 090-0352 | 2 | $87.5 CAD | |
| 13 | Nut | 11503-00800-XXА | 09.0417 | 4 | Price on request | |
| 14 | Cover | 10403-03900-N0А | 1 | |||
| 15 | Screw | 11502-08300-N0А | 6 | |||
| 16 | Washer | 11504-04700-XXА | 05.0045 | 1 | Price on request | |
| 17 | Washer | 11504-04500-XXА | 1 | |||
| 18 | Screw | 11502-06400-XXА | 1 | |||
| 19 | Screw | 11502-02300-XXА | 09.0433 | 1 | Price on request | |
| 20 | Lock | 10400-02700-N0А | 090-1804 | 1 | $19 CAD | |
| 21 | Handle | 10400-02300-XXА | 04.0132, 090-0302 | 1 | $12.5 CAD | |
| 22 | Screw | 11502-06000-XXА | 05.0767 | 2 | Price on request | |
| 23 | Nut | 11503-10800-XXА | 02.0225 | 7 | ||
| 24 | Visor | 10400-02800-N0А | 1 | |||
| 25 | Handle | 10403-03300-N0А | 1 | |||
| 26 | Nut | 11503-08000-XXА | 02.0205 | 4 | Price on request | |
| 27 | Washer | 11504-09900-N0А | 4 | |||
| 28 | Screw | 11502-04600-XXА | 02.0777 | 4 | Price on request | |
| 29 | Wiper blade | 10403-01400-XXA | 1 | |||
| 30 | Compactor | 10401-00300-N0A | 1 | |||
| 31 | Rivet | 11507-01600-XXА | 02.0224 | 11 | Price on request | |
| 32 | Tank | 11106-00600-N0A | 1 | $24 CAD | ||
| 33 | Screw | 11502-01400-XXA | 05.0464 | 3 | Price on request | |
| 34 | Sleeve | 10403-00300-N0A | 1 | |||
| 35 | Valve | 11106-00800-N0A | 1 | |||
| 36 | Stand | 10403-00200-N0A | 1 | |||
| 37 | Washer | 11504-04200-XXA | 03.0515 | 1 | $0.5 CAD | |
| 38 | Nut | 11503-00700-XXA | 09.0416, 090-1195 | 1 | $0.9 CAD | |
| 39 | Sleeve | 10403-00400-N0A | 1 |
